Methodology
Our methodology for the Standard Penetration Test adheres strictly to ASTM D1586, the recognised standard for measuring soil resistance. Using a 63.5 kg hammer dropped 760 mm, we drive a split-spoon sampler into the subsurface, recording blow counts (N-values) at 1.5-metre intervals. Data is corrected for overburden pressure and energy efficiency. The test is complemented by Cone Penetration Test (CPT) for continuous profiling and DPSH Dynamic Probing for deeper strata. Our integrated approach ensures reliable soil classification, liquefaction assessment, and foundation design parameters. We maintain rigorous quality control, with equipment calibrated to NATA standards. For more on our services, see our page on Standard Penetration Test (SPT).
Reference Technical Parameters
| Parameter | Reference Value |
|---|---|
| Hammer Energy Efficiency | 60–80% (calibrated per ASTM D4633) |
| Blow Count (N-value) Range | 2–50 blows/300 mm |
| Depth of Investigation | Up to 60 m (standard), 100 m (with DPSH) |
| Sampling Interval | 1.5 m (standard), 0.75 m (critical zones) |
| Seismic Zone Factor (AS 1170.4) | 0.08–0.18 depending on location |
Local Considerations — Australia
Australia's geotechnical landscape spans from the alluvial plains of the Murray-Darling Basin to the weathered profiles of the Pilbara. Seismic zones, as per AS 1170.4, range from low (Zone 0) in central regions to moderate (Zone 2) along the southern coast. Our team adapts SPT methods to local conditions: in Adelaide, for instance, the presence of calcareous sands requires continuous sampling to avoid refusal. In the northern parts of the country, such as near Brisbane, residual soils from basalt weathering necessitate careful energy correction. For a city-specific perspective, explore our page on Adelaide.
Request a Quote
Our team reviews your project and issues an initial report at no cost.
Or write us directly at contact@standardpenetrationtest.org
Applicable Standards
- AS 1289.6.3.1 - Soil strength and consolidation tests – Determination of the penetration resistance of a soil – Standard penetration test (SPT)
- ASTM D1586 - Standard Test Method for Standard Penetration Test (SPT) and Split-Barrel Sampling of Soils
- AS 1170.4 - Structural design actions – Earthquake actions in Australia
- Eurocode 7 - Geotechnical design (reference for international projects)
Frequently Asked Questions
What is the Standard Penetration Test (SPT) and how is it performed in Australia?
The SPT is an in-situ test that measures soil resistance by driving a split-spoon sampler with a 63.5 kg hammer. In Australia, it is performed per AS 1289.6.3.1 and ASTM D1586, with blow counts recorded at 1.5 m intervals. It is widely used for foundation design and liquefaction assessment.
What are the typical N-values for Australian soils?
N-values vary widely: soft clays may yield 2–5, sands 10–30, and dense gravels or weathered rock exceed 50. In Sydney's Hawkesbury Sandstone, N-values often exceed 100, indicating high bearing capacity. Corrections for overburden and hammer energy are applied per AS 1289.
Which Australian standards govern the Standard Penetration Test?
The primary standard is AS 1289.6.3.1, which specifies the test procedure and equipment. Additionally, ASTM D1586 is commonly referenced for international consistency. Seismic design follows AS 1170.4, and soil classification uses the Unified Soil Classification System (USCS).
